Description
This series is a special seal designed specifically for cleaning and lubricating fluids, such as water, different types of oils, solvents, and raw materials [viscosity<2%]. It is commonly used in pumps in paper mills, cardboard mills, and power plants. It is specifically designed for the Sulzer® APP and APT series 。pumps.
Features
- Multi spring compensation structure, ensure accurate uniform seal face loading.
- Using pins to secure the stationary ring for greater stability.
- Suitable for general working conditions and can be used for plans such as Plan 01, 02, 11, 12, 13, 21, 22 etc.
- Shaft diameters of 30, 40, 50, 60, 80, 90, etc。
- Operation Parameters
Temperature： -20ºC~120ºC
Pressure： 0~15 Bar
Linear Speed： Up to 20 M/S
Sealing product：
Acid, alkaline, low percentage of pulp, water, oil and other similar media
Materials：
Seal Face
Carbon,SiC, SSiC, TC
Rubber
EPDM, FKM,FFKM,Chemraz
Springs
Nimonic steel
Metal Parts
AISI 329 (standard), titanium, UHB
